53ft High Cube Containers | New & Used

53ft HC Containers

Maximize your storage and transport with 53ft high cube shipping containers. Extra length and height, durable construction, and ideal for oversized cargo or projects

53ft High Cube Shipping Container

Product Description

Item Title: 53ft High Cube Shipping Container (9'6" Tall) – Maximum Capacity Wide-Body Conex Box

The Ultimate Solution for Large-Scale Domestic Storage and Logistics The 53ft High Cube (HC) shipping container is the largest intermodal asset in the North American market. Often referred to as a Wide-Body Conex or Domestic High Cube, this unit is 13 feet longer and 6 inches wider than a standard 40ft ISO container. It is specifically engineered for businesses and shippers that need to maximize volumetric efficiency while utilizing the North American rail and highway infrastructure.

With a massive internal capacity of approximately 3,830 to 3,970 cubic feet, the 53ft High Cube offers roughly 60% more cargo volume than a standard 40ft unit. The unique 102-inch (8'6") exterior width allows for the side-by-side loading of standard pallets with zero wasted space, a feature not possible in international ISO containers. It is the premier choice for large-scale inventory warehousing, oversized machinery storage, and high-end structural conversions.

Technical Specifications Table

Specification Category	Metric	Imperial	Notes
External Dimensions	16.15 m L x 2.59 m W x 2.90 m H	53' L x 8' 6" W x 9' 6" H
Internal Dimensions	15.93 m L x 2.49 m W x 2.71 m H	52' 3" L x 8' 2" W x 8' 10" H
Door Opening	2.49 m W x 2.58 m H	8' 2" W x 8' 5" H
Internal Volume	108.5 - 112.4 m³	3,830 - 3,970 ft³	Largest Intermodal Unit
Tare Weight (Empty)	~4,876 - 5,490 kg	~10,750 - 12,103 lbs	Varies by construction
Max Gross Weight	30,480 - 32,500 kg	67,200 - 71,650 lbs
Max Payload	~25,460 - 27,850 kg	~56,130 - 61,400 lbs
Pallet Capacity	30 Standard (48"x40")	-	Single layer

Specification Category

Metric

Imperial

Notes

External Dimensions

16.15 m L x 2.59 m W x 2.90 m H

53' L x 8' 6" W x 9' 6" H

Internal Dimensions

15.93 m L x 2.49 m W x 2.71 m H

52' 3" L x 8' 2" W x 8' 10" H

Door Opening

2.49 m W x 2.58 m H

8' 2" W x 8' 5" H

Internal Volume

108.5 - 112.4 m³

3,830 - 3,970 ft³

Largest Intermodal Unit

Tare Weight (Empty)

~4,876 - 5,490 kg

~10,750 - 12,103 lbs

Varies by construction

Max Gross Weight

30,480 - 32,500 kg

67,200 - 71,650 lbs

Max Payload

~25,460 - 27,850 kg

~56,130 - 61,400 lbs

Pallet Capacity

30 Standard (48"x40")

Single layer

Critical Delivery & Site Requirements

⚠️ WARNING: The 53ft container requires the most extensive delivery site of any standard unit.

Linear Clearance: A tilt-bed "roll-off" delivery truck requires a minimum of 120 to 135 feet of straight-line ground clearance to unload. The truck must be able to pull out from under the unit as it slides off the trailer.

Turning Radius: Due to the trailer length, a wide turning area (at least 14ft wide) is required for access gates and driveways.

Overhead Clearance: While the container is 9'6" tall, it can reach an apex height of 21 feet during the offloading process. Check for power lines, building eaves, and tree branches.

Ground Conditions: Ground must be firm, dry, and level (gravel, pavement, or compacted dirt). A 45,000 lb loaded truck will sink in soft soil or wet grass.

Foundation: We strongly recommend placing the container on concrete pads or railroad ties under the four corner posts and mid-points to ensure the frame remains level and doors operate smoothly.

Please refer to the lists of our available 53ft HC shipping containers below for each location. Let us know if you require any further assistance
