Technical Specification: 40ft High Cube (HC) Refrigerated Container
Status: New / One-Trip Condition
The 40ft High Cube (HC) Refrigerated Container represents the pinnacle of mobile cold storage technology. These "One-Trip" units are manufactured in state-of-the-art facilities and shipped once to their destination country with a single load of cargo to offset shipping costs. For the end-user, this means receiving a unit in pristine condition with the latest energy-efficient machinery and a full structural lifespan.
The "High Cube" designation provides an additional 1 foot (30 cm) of vertical height compared to standard units, offering significantly better airflow and higher pallet-loading capacity.
2. Dimensions & Weight Specifications
| Category | Metric (mm/kg) | Imperial (ft-in/lbs) | Technical Note |
| External (L×W×H) | 12,192 × 2,438 × 2,896 | 40' 0" × 8' 0" × 9' 6" | High Cube profile |
| Internal (L×W×H) | ~11,585 × 2,285 × 2,545 | ~38' 0" × 7' 6" × 8' 4" | Insulated usable space |
| Max Cargo Height | 2,420 mm | 7' 11" | Internal "Red Line" limit |
| Tare Weight | ~4,600 – 4,950 kg | ~10,141 – 10,912 lbs | Includes cooling unit |
| Max Gross (MGW) | 34,000 – 35,000 kg | ~74,957 – 77,161 lbs | Heavy-rated frame |
| Max Payload | ~28,500 – 30,400 kg | ~62,831 – 67,020 lbs | Net cargo capacity |
| Internal Volume | ~67.3 m³ | ~2,380 ft³ | Total insulated capacity |
3. Refrigeration Machinery & Electrical
Temperature Range: -30°C to +30°C (-22°F to +86°F).
Humidity Control: Adjustable de-humidification range (65%–95%) for sensitive chilled produce.
Fresh Air Exchange: Adjustable vent (0–285 m³/hr) to manage CO2 levels.
Power: 3-Phase 460V (60Hz) or 3-Phase 380V (50Hz). Requires a 30 Amp circuit.
Please refer to the lists of our available 40ft HC New Reefer containers below for each location. Let us know if you require any further assistance.
